PRODUCT SPECIFICATIONS   30W

Model

30T3 Series

▓ INPUT

Input voltage

100 to 240 VAC

Input frequency

47 to 63 Hz

Input current

MAX 0.95A

Safety ground leakage current

0.25mA max @ 240 VAC 50Hz

▓ OUTPUT

Output voltage

See Rating Chart

Output current

See Rating Chart

Output power range

Ripple & Noise

2% peak to peak maximum

Overvoltage protection

Optional

Overcurrent protection

All outputs protected to short circuit conditions

Temperature coefficient

All outputs ±0.04% per degree C maximum

▓ ENVIRONMENTAL

Operation temperature

0℃ to +40℃

Storage temperature

-25℃ to + 85℃

Relative Humidity

5% to 95% RH (non-condensing)

▓ GENERAL

Efficiency

60% minimum at Max Load

Hold-up time

5 msec minimum at maximum load

Line regulation

±1% maximum at full load

Inrush current

Max 40A @ 115 VAC or Max 60A @230 VAC

Withstand voltage

6000 VDC from input to output, 1min.

Insulation resistance

50 MΩ DC500V between input & output.

Mean time between failure

100,000 hours minimum at full load at 25℃ ambient

EMI requirements

(a). FCC 47 CFR , PART 18

(b). EN55011:2007

Safety requirements

(a). UL 60601-1 3^rd

(d). TUV EN60601-1 3^rd

(b). CUL-CAN/CSA C22.2 no. 60601-1:08 2^nd

(e). JET/PSE (only 30T3-12-2500)

(c). CB IEC 60601-1 ed3

Mechanical

Outline Dimension: LxWxH  30T3: 102x58x38 mm
